100mm & 160mm diameter pressure gauge with a bolted body diaphragm seal separating the internals of the pressure gauge from the process media.
Designed for applications where the process media would solidify, block or clog a conventional bourdon tube style pressure gauge such as sludge, slurry, etc. The bore through the process connection is increased to 10mm to help the process media drain from the lower housing below the diaphragm.
This design of seal can be supplied in either threaded or flanged process connections and a wide range of wetted parts material including PTFE are available.
