(003) 50mm Diameter HVAC Pressure Gauge
50mm diameter bourdon tube pressure gauge designed for use in plant rooms, heating systems and general utility applications. These instruments are suitable for all gaseous and liquid media that are not highly viscous and that will not solidify, crystallize, attack or corrode brass. This gauge is designed for applications according to the European Standard EN837-1.
These instruments are not designed for application outside or where the environment is very damp. For such applications we suggest Model 50BG701 Series.
Generally Available Ex-Stock
Product Details
| Model Number: | 50BD201 Series |
| Nominal Sizes: | 50mm |
| Accuracy Class: | 2.5 (2.5% FSD) |
| Ranges: | 0-1 Bar / 15 PSI to 0-28Bar / 400 PSI |
| Working Pressure: | Static Load 75% Scale |
| Calibration Temp: | 20C |
| Temperature: | Medium +60C (Ambient -20 / + 60C) |
| Protection: | IP32 |
| Connection: | 1/8" & 1/4" BSPT Available Ex-Stock |
| Measuring Element: | Brass |
| Movement: | Brass Bourdon Tube |
| Housing & Bezel: | Black Painted Steel Case |
| Dial & Pointer: | White Plastic Dial / Metal Black Pointer |
| Window: | Push Fit Clear Plastic |
| Mounting: | Direct Mount Bottom or Back Entry |
| Availability | Generally Available Ex-Stock |
Call us on 0044 (0)1233 730999 for more information |
 |
|
50mm HVAC Pressure Gauge |
