Chart Recorder - Wall & Panel Mounted (166mm, 223mm or 300mm Charts)

The Ashford Instrumentation Ltd 9" wall or panel mount pressure and temperature stainless steel case chart recorder.

This portable instrument can be manufactured with up to 3 channel inputs for temperature and / or pressure measurement.

Scales available include 1 Hour, 4 Hours, 12 Hours, 24 Hours or 7 Days and the drive can be manufactured either mains-powered, battery operated or mechanical spring-wound.

Features include zero adjustable pointer and ATEX options. Each recorder is supplied with 100 charts and extra felt tip pens.

The Ashford Instrumentation Ltd range of bench mount, wall mount, panel mount and portable PELI case chart recorders are available in a range of chart sizes. Please CLICK HERE for further details.

Pressure & temperature inputs can be configured 3 X Pressure, 2 X Pressure & 1 X Temperature, 1 X Pressure & 2 X Temperature of 3 X Temperature.
